YSX1007W Mobile Dental X-Ray Unit
Product Introduction
YSX1007W is a mobile dental X-ray unit sourced and integrated by SYRJ Medical for dental clinic project evaluation. The page presents source-verified technical specifications for equipment review and project planning.
Specification
| Tube Voltage | 70 kV ±10% |
| Tube Current | 7 mA ±15% |
| Focal Spot | 0.8 mm |
| Anode Angle | 19° |
| Half-Value Layer | 1.6 mmAl at 70 kV |
| Inherent Filtration | ≥2.1 mmAl |
| Leakage Radiation | <0.07 mGy/h at 1 m |
| Input Power | AC 220 V ±10%, 50–60 Hz |
| Rated Power | 900 VA |
| Fuse | 4 A / 6.3 A |
Sale Service
| Installation | None |
| Warranty | None |
| Return | None |
| Exchange | None |
FAQ
Q1: What are the main technical parameters of the YSX1007W mobile dental X-ray unit?
A1: The YSX1007W operates at 70 kV ±10% tube voltage and 7 mA ±15% tube current, with a 0.8 mm focal spot and a 19° anode angle.
Q2: What are the filtration specifications of the YSX1007W?
A2: The YSX1007W has a half-value layer of 1.6 mmAl at 70 kV and inherent filtration of ≥2.1 mmAl.
Q3: What power supply does the YSX1007W require?
A3: It requires AC 220 V ±10%, 50–60 Hz input power, with a rated power of 900 VA and a 4 A / 6.3 A fuse.
Q4: What is the leakage radiation level of the YSX1007W?
A4: Leakage radiation is specified as <0.07 mGy/h at a distance of 1 m.
Q5: How is the YSX1007W intended to be used in a dental clinic project?
A5: The YSX1007W is a mobile dental X-ray unit sourced and integrated by SYRJ Medical for dental clinic project evaluation. This page presents source-verified technical specifications for product review.
